Multi Functional Drum Type Direct Activated Pressure Sustaining Valve
Product Details:
- Application Air / Water / Steam / Gas & Oil
- Size 1.1/2" to 24"
- Product Type Direct Activated Pressure Sustaining Valve Multi Functional Drum Type
- Material Casting
- Temperature Normal Temperature
- Structure Pressure Reducing
- Power Manual
- Supply Ability : 1 Per Day
- Click to view more
Price And Quantity
- 1 , , Piece
- 19770 to 472752 INR/Piece
Product Specifications
- Thread, Flange Type
- Manual
- Pressure Reducing
- Direct Activated Pressure Sustaining Valve Multi Functional Drum Type
- Normal Temperature
- Air / Water / Steam / Gas & Oil
- 1.1/2" to 24"
- DSF
- Casting
Trade Information
- ICD - Ahmedabad / JNPT - Nhava Seva
- Cash Against Delivery (CAD), Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Western Union
- 1 , , Piece Per Day
- 2 Week
- Yes
- Contact us for information regarding our sample policy
- Plastic Polythene Bag / Corrugated or Wooden Box
- Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
- All India
Product Description
Multifunctional direct activated pressure sustaining valve with heavy duty design that is highly demanded due to durability and sturdy design is manufactured and supplied by our company. Our plumbing unit is constructed from cast iron. A protective anti-corrosive coating ensures that it is suitable for corrosive as well as non-corrosive systems. The end connections of the multifunctional drum type direct activated pressure sustaining valve are arranged in a series for rigid connections.
Features:
- The installation of pipes for users involves the use of pressure sustaining valves. Under normal conditions and emergencies, it matches up with the minimum working pressure inside the water pipe, and maintains a constant pressure throughout the pipe during normal use.
- Installation of pressure sustaining valve in water supply pipes can sustain the maximum working pressure.
- Pressure adjusting range : 0.2 ~ 4 kgf/cm ,3 ~ 10 kgf/cm , (1 kgf/cm = 14.2 psi)
- The working pressure should be more than 0.3 kgf/cm2 and gate fully open with 1.5 kgf/cm2, it is important to check the pressure before installation.
Specification
| Minimum Order Quantity | 1 Piece |
| Media | Air / Water / Steam / Gas & Oil ect. |
| Size | 1.1/2" to 24" |
| Design | High Flow |
| Brand | AIRA |
| Model | DSF |
| End Connection | Flanged 150# & 300 |
| Temperature | Upto 85 Degree Celsius & Steam : Upto 180 Degree Celsius |
| Country of Origin | Made in India |
| Body | Cast Iron / S. G. Iron / Ductile Iron / WCB / CF8 / CF8M |
| Piston | S. S. 304 / S. S. 316 |
| Seals | NBR / Viton |
| Pressure Adjusting Range | 1 ~ 6 KGS/CM2 / 4 ~ 10 KGS/CM2 |
| Plug | S. S. 304 / S. S. 316 |
| Spring | S. S. 304 |
| Max Inlet Pressure | 12 KGS/CM2 |
| Operation | Pilot Operated |
