C Way 3 Way Floating Ball Valve Screwed & Flanged
Product Details:
- Pressure Medium Pressure
- Product Type C Way 3 Way Floating Ball Valve
- Connection Screwed - BSP (NPT On Request) & Flanged 150 Class
- Structure Ball
- Size 1/2" to 8"
- Material Casting
- Application Air / Water / Oil / Gas & Chemical
- Supply Ability : 100 , , Box Per Month
- Click to view more
Price And Quantity
- 1 , , Box
- 5770 to 267680 INR/Piece
Product Specifications
- 1/2" to 8"
- Ball
- C Way 3 Way Floating Ball Valve
- Casting
- Medium Pressure
- Air / Water / Oil / Gas & Chemical
- Screwed - BSP (NPT On Request) & Flanged 150 Class
Trade Information
- ICD - Ahmedabad / JNPT - Nhava Seva
- Cash Against Delivery (CAD), Cash Advance (CA), Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T), Western Union
- 100 , , Box Per Month
- 5 Days
- Yes
- Contact us for information regarding our sample policy
- Plastic Polythene Bag / Corrugated or Wooden Box
- Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
- All India
Product Description
C Way 3 Way Floating Ball Valve Screwed & Flanged
"AIRA" Hand Lever & Gear Operated 2 Piece design "C" Way Floating Ball Valve engineered multiple On/Off operation in the down stream. Side entry 3 Way ball valve offers diverting and mixing / selection flow patterns and often eliminates the need for two valves. The T - Port / L - Port configuration is available as a 2 Piece design in two in two seat and four seat configuration this is extremely versatile in various configurations and the full port design is easily automated as it comes in and is available with various seat material for various pressure and temperature range. "C Way" ball valve designed for using in the several conditions such as like Chemical, Pharmaceutical, Food, Petrochemical, Energy, Plastic, Oil & Gas, Cement & Lubrication.
Specification
| Minimum Order Quantity | 1 Piece |
| Size | 1/2" to 3" - Screwed & 1/2" to 8" - Flanged |
| Pressure | Upto 10 KGS/CM2 |
| Brand | AIRA |
| Series | CW |
| Temperature | PTFE : Upto 180 Degree Celsius & PEEK : Upto 250 Degree Celsius |
| Design Standard | ASME B 16.34 / BS EN ISO 17292 |
| Country of Origin | Made in India |
| Model | WCS / WCF / WCG |
| Design | 2 Piece |
| Body | ASTM A216 Gr. WCB / ASTM A351 Gr. CF8 / CF8M / CF3M |
| End Connection | Screwed - BSP ( NPT On Request ) & Flanged 150# |
| Ball | ASTM A351 Gr. CF8 / CF8M / CF3M |
| Seals | PTFE / GFT / CFT / PEEK |
| Ends | Screwed - BSP / Flanged 150# |
